The IK2 transmitter has a compact control panel for 2 optical joysticks or 4 paddle-sticks for basic industrial and mobile applications.

Some interesting features:

  • Up to 2 joysticks or 4 paddles
  • Start button (Super Key) and stop button
  • Customizable layout
  • Customizable configuration
  • External and removable configuration module (EEPROM)
  • Dual-band radio module (usable for full full-duplex communication with the paired receiver)
  • External LED indication for operational status and troubleshooting
  • Optional LCD (128×64) display
  • Non-slip grip

Ask our specialists for information!
Get in touch

Categories: ,


Joystick transmitter IK2
Stop function Cat. 3 – PLd
Enclosure rating IP65/NEMA4
Frequency band Dual-band: 400-930 MHz
Controls 2 joysticks / 4 paddles
Removable EEPROM Yes
Status indication LED
Weight with battery 950 g
Dimensions 184 x 173.4 x 158.7 mm
Operational temperature -20 °C to +70 °C
Battery model BT11K
Battery autonomy +16h
